ASUS PRIME B850‑PLUS WIFI – Placă de bază ATX, AM5, DDR5, PCIe 5.0, M.2, Wi‑Fi 6E, 2.5GbE

General:

• Brand: ASUS

• Model: PRIME B850‑PLUS WIFI

• Format: ATX

• Chipset: AMD B850

• Socket: AM5

• Compatibilitate CPU: Ryzen 7000 / 8000 / 9000 Series

Memorie:

• Tip: DDR5

• Sloturi: 4 × DIMM

• Capacitate max.: 256 GB

• Frecvență: până la 8000 MT/s (O.C.)

• Configurație: Dual Channel

• Integritate: Non‑ECC, on‑die ECC

• Tehnologii: AMD EXPO, AEMP

Audio:

• HD Audio 8‑canale

• Standard: High Definition Audio

Rețea:

• LAN: 2.5 Gigabit Ethernet

• Wireless: Wi‑Fi 6E (802.11ax)

• Bluetooth: 5.3

Sloturi & Expansiune:

• 1 × PCIe 5.0 x16

• 1 × PCIe 4.0 x16 (x4 mode)

• 2 × PCIe 3.0 x16 (x1 mode)

• 2 × M.2 PCIe 4.0 (2280)

• 1 × M.2 PCIe 5.0 (2242/2260/2280/22110)

Stocare:

• 4 × SATA III

• RAID: 0 / 1 / 10 / 5

• RAID M.2: 0 / 1 / 10 / 5

• Tehnologie: AMD RAID Xpert2

Conectivitate Externă:

• 1 × USB‑C 3.2 Gen 2

• 3 × USB 3.2 Gen 2

• 2 × USB 3.2 Gen 1

• 2 × USB 2.0

• 1 × DisplayPort

• 1 × HDMI

• 2 × antene Wi‑Fi

• Audio: mic, line‑out, line‑in

Conectivitate Internă:

• 6 × USB 2.0 header

• 2 × USB 3.2 Gen 1 header

• 1 × USB‑C 3.2 Gen 1 header

• Audio header

• Serial header

• Thunderbolt 4 header

• SPDIF out header

• SPI header

Alimentare:

• 24‑pin ATX

• 4‑pin ATX12V

• 8‑pin ATX12V

Funcții & Tehnologii:

• ASUS EZ Flash 3

• CrashFree BIOS 3

• ASUS 5X Protection III

• ASUS DIGI+ VRM

• ASUS SafeSlot

• ASUS Aura Sync

• ASUS Q‑Design (Q‑DIMM, Q‑Slot, Q‑LED Core, Q‑Antenna, Q‑Dashboard)

• BIOS FlashBack button + LED

• VRM heatsink

• M.2 heatsink

• Pre‑mounted I/O shield

• 8+2+1 Phase Power Design

• 6‑Layer PCB

Dimensiuni:

• Lățime: 30.5 cm

• Adâncime: 24.4 cm

Accesorii Incluse:

• ASUS Wi‑Fi Q‑antenna

• Pachet M.2 rubber

• 3 × seturi șuruburi M.2

• 2 × cabluri SATA

Software Inclus:

• Armoury Crate

• ASUS AI Advisor

• ASUS AURA Creator

• ASUS CPU‑Z

• ASUS DriverHub

• ASUS Fan Xpert 2+

• ASUS GlideX

• TurboV Core

• WinRAR (trial)

• Adobe Creative Cloud (trial)

• Norton 360 Deluxe (trial)
